Traditionally, many industries use scanned 3D data as part of their design processes. In the past, this has required a time-consuming, and sometimes complicated process. Irregular shapes, in particular, required extensive reverse engineering so that they could be used for 3D printing, mold design, analysis, or other uses. NX allows you to bring the scanned data in as facets, so there's no need to map surfaces, create solids, or do any other manual shape creation. You can scan your data and immediately begin building supports for 3D printing, creating molds based on the shape, including it in an assembly, analyzing it, or performing any other operation that you would do with CAD data. Easily import and optimize scanned data. NX directly imports polygon facet data acquired by scanning physical objects. NX allows you to bring the scanned data in as facets, so there's no need to map surfaces, create solids, or do any other manual shape creation. You can scan your data and immediately begin building supports for 3D printing. With rapid surfacing tools in NX, you can automatically fit curves, splines and surfaces to the faceted data, creating precise CAD geometry for subsequent design engineering. NX also includes tools for comparing the scanned data to the CAD geometry in order to maintain tolerances. The resulting models help accelerate downstream design, simulation and manufacturing processes. In conjunction with powerful 3D design tools, Solid Edge delivers smart functionality to work with mesh, or triangle-based data. Bodies can be imported from other systems, digitally scanned or products of a generative design analysis. All of these come in as a mesh of triangles (or facets) and in many cases require further design modification. Solid Edge provides intuitive mesh cleanup tools to remove any errors that may have resulted from the import process, allowing designers to obtain a workable set of triangles. Once you have a sound mesh, regions can be identified and created, and those regions can be further extracted as surfaces and edited using traditional surface modeling tools.
Reverse Engineering
Rapidly Create CAD Models from Physical Objects
Convergent Technology
The first technology of its kind, Convergent Modeling ™ Technology allows designers to combine facets, surfaces, and solids in one model without converting data. This allows facet data to now be an equal part of the design process
Easily Import and Optimize Scanned Data
Faster Modeling from Scanned Data
Reverse Engineering: from 3D Scanning to CAD - Solid Edge
