Understanding the operating environments for intricate mechanical systems – like the mechanisms in photocopiers, sliding automotive sunroofs, or aircraft wing flaps – can be challenging. Many CAD-based tools offer kinematic solutions that help designers cycle a mechanism through its mechanical path for interference checking. Kinematics alone, however, doesn’t provide all the critical information you need, such as the dynamic loads generated by moving parts that can be used to size motors. Simcenter 3D offers multibody dynamics simulation capabilities that go beyond simple kinematics. Motion analysis calculates the reaction forces, torques, velocities, acceleration and more for mechanical systems. Simcenter 3D lets you directly convert CAD geometry and assembly constraints into an accurate motion model, while the embedded motion solver and robust post processing capabilities allow the study of a broad range of product behaviors. Kinematics is the branch of classical mechanics which describes the motion of points, bodies (objects), and systems of bodies without consideration of the masses of those objects nor the forces that may have caused the motion. Kinematics as a field of study is often referred to as the “geometry of motion”. kinematics is used to describe the motion of systems composed of joined parts (multi-link systems) such as an engine, a robotic arm or the skeleton of the human body. Understanding the operating environments for intricate mechanical systems like the mechanisms in photocopiers, sliding automotive sunroofs, or aircraft wing flaps can be challenging. Many CAD tools offer kinematic solutions that help designers cycle a mechanism through its mechanical path for interference checking. Kinematics alone however, doesn’t provide all the critical information an engineer needs, such as the dynamic loads generated by moving parts that can be used to size motors for example. NX CAE offers multibody dynamic simulation capabilities that go beyond simple kinematics. Motion simulation calculates the reaction forces, torques, velocities, acceleration and more for mechanical systems. The integration with NX lets engineers directly convert . CAD geometry and assembly constraints into an accurate motion model, while the embedded RecurDyn motion solver and rich post-processing capabilities allow the study of a broad range of product behavior.
Motion Simulation
Integrated Multibody Dynamics Simulation
Kinematic Motion
Dynamic Motion
